Lenovo ThinkCentre M90s 11D10048UK Small Form Factor PC, Intel Core i5-10500 vPro, 16GB RAM, 512GB SSD, DVDRW, Windows 10 Pro with Keyboard and Mouse

Lenovo ThinkCentre M90s 11D10048UK Small Form Factor PC, Intel Core i5-10500 vPro, 16GB RAM, 512GB SSD, DVDRW, Windows 10 Pro with Keyboard and Mouse

Regular price £532.00 GBP
Regular price Sale price £532.00 GBP
Sale Sold out
Shipping calculated at checkout.
Faster than the speed of thought
The ThinkCentre M90s SFF desktop PC runs at the speed of human imagination. With up to 10th Gen Core i5 vPro processors and 16GB DDR4 UDIMM (2933Mhz) memory, it has the power you need to run the demanding software that your industry requires.

Security inside and out
ThinkCentre devices allow your employees to innovate fearlessly with the reinforced security of ThinkShield. It's the most comprehensive end-to-end security solution, featuring an optional self-healing BIOS, discrete Trusted Platform Module (dTPM) 2.0 chip, Smart USB protection, and more that can be customized to meet your needs. The Intel vPro accelerates business productivity, safeguards data, and lets you gain long-term stability. Plus, Kensington lock slots and chassis e-locks provide physical security to protect against theft.

Exponential growth
Your business will never outgrow the ThinkCentre M90s small form factor PC, which offers an array of HDD and SDD expansion slots, giving you the ability to swap in newer and bigger storage drives as your needs expand. Add graphics cards to support industry-specific imaging equipment, use the plentiful expansion slots to connect to legacy peripheralsthe possibilities are endless.

Make every minute a work minute
Keep the ThinkCentre M90s desktop connected to the internet and up to date even in sleep mode with optional Modern Standby (requires an SSD). It saves precious time so you can keep work moving efficiently. Additionally, it offers a more convenient user experience with the ability to connect to three displays and a USB-C port located on the front panel that enables quick data sharing.

Comprehensive manageability
IT professionals will appreciate that ThinkCentre M90s is easy to deploy and easy to manage from both a software and hardware standpoint. Expansion is hassle-free as well, thanks to an ease-of-use design that offers quick access to the DIMM, HDD, SDD, and optical disc drive. The Intel vPro platform is built for business, so you have the assurance that you're getting everything you need to run productively, more securely, and cost-effectively, 24/7.

Intel® Core™ i5-10500 (6C / 12T, 3.1 / 4.5GHz, 12MB)

Integrated Intel® UHD Graphics 630

Intel® Q470 Chipset

1x 16GB UDIMM DDR4-2666

Memory Slots
Four DDR4 DIMM slots, dual-channel capable

Max Memory
Up to 128GB DDR4-2933

512GB SSD M.2 2280 PCIe® 3.0x4 NVMe® Opal

Optane Memory

Storage Support
Up to four drives, 1x 2.5"/3.5" HDD + 1x 2.5" HDD + 2x M.2 SSD
- 2.5" HDD up to 1TB each
- 3.5" HDD up to 2TB each
- M.2 SSD up to 2TB each
- Optional Intel® Optane™ Memory, M.2

Card Reader
3-in-1 Card Reader


Audio Chip
High Definition (HD) Audio, Realtek® ALC623-CG codec


Power Supply
180W 85%

USB Traditional Keyboard, Black, English (UK)

USB Calliope Mouse, Black

Front Access HDD

Optional Bay
Optional 2.5" Bay

Expansion Slots
One PCIe® 3.0 x16, low-profile (length < 155mm, height < 68mm)
One PCIe® 3.0 x4, low-profile (length < 155mm, height < 68mm)
One PCIe® 3.0 x1, low-profile (length < 155mm, height < 68mm)
One dummy slot, only bracket for optional port extension
Three M.2 slots (one for WLAN, two for SSD)

Case Color


Carry Handle

Dust Filter

Form Factor
SFF (8.2L)

Dimensions (WxDxH)
92.5 x 297.7 x 339.5 mm (3.6 x 11.7 x 13.4 inches)

Around 5.3 kg (11.7 lbs)

Integrated 100/1000M

WLAN + Bluetooth

Front Ports
1x USB-C® 3.2 Gen 1
2x USB 3.2 Gen 1
2x USB 3.2 Gen 2
1x headphone / microphone combo jack (3.5mm)
1x microphone (3.5mm)
Optional Front Ports (configured)
1x card reader

Rear Ports
4x USB 3.2 Gen 1
2x DisplayPort™
1x Ethernet (RJ-45)
1x line-out (3.5mm)
1x serial (9-pin)
Optional Rear Ports (configured)

Monitor Cable

Security Chip
Discrete TPM 2.0, TCG certified

Fingerprint Reader
No fingerprint reader

Physical Locks
Smart Cable Clip
Kensington® Security Slot™, 3 x 7 mm
Padlock Loop

Kensington Cable Lock

Smart Cable Clip
Smart Cable Clip

Chassis E-Lock

Chassis Intrusion Switch
Chassis Intrusion Switch

System Management
Intel® vPro®

Base Warranty
3-year, Onsite

Included Upgrade
1Y Premier Support from 3Y Onsite WHB (CPN)

Green Certifications
EPEAT™ Silver Registered
ErP Lot 3
RoHS compliant
TCO Certified 8.0

Mil-Spec Test
MIL-STD-810H military test passed (Low Pressure [Altitude], High Temperature, Low Temperature, Temperature Shock, Humidity, Sand and Dust, Vibration, Shock, Fungus, Solar Radiation)

Operating System
Windows® 11 DG Windows 10 Pro 64, English
